Terex Manlift Specifications
Terex is a Westport, Connecticut company that specializes in making in manufacturing construction machinery. Machines such as boom lifts, aerial lifts and manlifts. These kinds of machinery are designed to facilitate access to places which are hard to reach, buildings and roofs, large equipment, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also known as OSHA refers to a power-driven endless belt. This belt only moves in one direction and includes platforms, or steps or handholds which are attached to the unit to be able to move employees from every floor.
TB85
The TB85 man lift by Terex provides a max working height at 91 feet. The platform's max height reaches 85 feet, whilst the maximum width of the model is 8.5 feet. The TB85 has dimensions that measure 9 feet, 1-inch high and 9 inches wide by 36 feet. This model offers a reach of 70 feet. The TB85 has a boom angle above horizontal measuring 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The maximum height of Terex's TB100 man lift is 106 feet and the platform's maximum height is 100 feet. The TB100 when stowed away, is roughly 8.5 feet wide by 9 feet high by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, while the max working height measures at 116 feet. The model is 9 feet, 4 inches high x 8 feet wide when stowed away. The TB110 provides a horizontal reach of 67 feet and a maximum width of 8 feet. This model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
