Usually the base that is bolted into a huge concrete pad provides the necessary support for a tower crane. The base is attached to a mast or a tower and stabilizes the crane which is affixed to the inside of the building's structure. Normally, this attachment point is to a concrete lift or to an elevator shaft.
Typically, the mast is a triangulated lattice structure measuring 0.9m2 or 10 feet square. The slewing unit is connected to the very top of the mast. The slewing unit consists of a gear and a motor which enable the crane to rotate.
Tower cranes may have a max unsupported height of 80m or 265 feet, while the minimum lifting capacity of a tower crane is 16,642 kg or 39,690 pounds with counter weights of 20 tons. Additionally, two limit switches are used to be able to make certain that the operator does not overload the crane. There is even another safety feature known as a load moment switch to make sure that the driver does not surpass the ton meter load rating. Finally, the maximum reach of a tower crane is 230 feet or 70 meters.
There is definitely a science involved with erecting a tower crane, specially because of their extreme heights. At first, the stationary structure has to be transported to the construction location by using a huge tractor-trailer rig setup. Then, a mobile crane is utilized in order to assemble the equipment part of the crane and the jib. After that, these parts are attached to the mast. The mobile crane then adds counterweights. Crawler cranes and forklifts may be a few of the other industrial machines which is usually used to erect a crane.
As the building is erected, mast extensions are added to the crane. This is how the crane's height is able to match the building's height. The crane crew uses what is called a climbing frame or a top climber that fits between the slewing unit and the top of the mast. A weight is hung on the jib by the work crew so as to balance the counterweight. Once complete, the slewing unit is able to detach from the top of the mast. In the top climber, hydraulic rams are utilized to adjust the slewing unit up an extra 6.1m or 20 feet. Next, the operator of the crane utilizes the crane to insert and bolt into position one more mast part piece.
